Efficient algorithm for cubic interpolation

General JUCE discussion
1

Hello,
I am working on fft analyser. And actually my analyser works great at the moment, but only when I use juce::Path::cubicTo(). And because as usual I add horizontal coordinates logarithmically calculated from my FFT bins so Paths nodes X coordinates are not spaced equally.

But now I need to draw it as bar chart. So I need points which are spaced equally. To do that I do something which is killing my CPU. The method is that I still create path with cubicTo(), but later for each equally spaced X I use: myPath[i].getClippedLine(Line<float>(x, getHeight(), x, 0.0f), false);

So to improve the efficiency I think I should create my own XY array. But then I need to interpolate Y coordinates for all equal spaced Xs by myself.
But I found out that cubic interpolation is not such simple subject so I would like to ask you if you know any good library to achieve such interpolation. I was looking at Boost Cubic B-Spline but it looks like it works only for functions with already equally spaced points, but as my FFT bins are spaced logarithmically so I think I need to find something else.

Or maybe there is anything which I missed in juce::Path But it looks like juce::Path::iterator iterates only through the nodes but not through any given X coordiates.

For any help great thanks in advance.
Best Regards.

2

Consider trying JUCE: PathFlatteningIterator Class Reference .

Alternatively: I haven’t used it but glancing over it, it seems the Spline class from the gin modules could solve your problem.

2 Likes
3

I figured this is worth sharing: the Gin spline implementation is based on this Cubic Spline Interpolation blog post, if there’s interest in rolling your own portable spline algorithm.

4

Hello,
great thanks for your answers. After an exhaustive search I found out the best way in my case would be Centripetal Catmull–Rom spline

On some other post I also found very nice video which I advice to watch for everyone who try to understand slines little bit more:

Best Regards.

5 Likes
5

A close relative is the Cubic Hermite Spline (linked on your Wikipedia link).
A great read is the blog post from our friend Signalsmith:

2 Likes
6

The Continuity of Splines is an absolute banger when it comes to a fully fledged video about splines, but the video that actually taught me how to implement a basic spline was this one:

2 Likes
7

I just want to drop in for people that visited this thread specifically to find a way to make a path for a spectrum analyzer.

It might be easier to just p.lineTo(x, y); linear interpolate between points and then…

auto outputPath = p.juce::Path::createPathWithRoundedCorners(48.f);

…rather than try to figure out p.cubicTo control points. Obviously if you’re trying to draw splines this is great info^ but I found myself here a lot when trying to smooth out my spectrum analyzer

1 Like
8

would it perform too bad to just linear phase lowpass the spectral information instead of interpolating them? cause i feel it should be rather cheap if you use an IIR filter going up and down the spectrum whenever it came out of the forward fft
